TM WITH OMNI-EC™ TECHNOLOGY AIRSTORM PRO™ FAN 54” AIRSTORM PRO™ AS-54EDDLP-PRO ™
WITH OMNI-EC™ TECHNOLOGY AIRSTORM PRO™ FAN The Hog Slat 54” AirStorm Pro™ Fan, built with premium components and advanced technology features the innovative Omni-EC™ direct drive motor to deliver powerful airflow, exceptional durability, and precise control for efficient, reliable ventilation performance. ADVANCED MOTOR TECHNOLOGY POWERED BY LEESON MOTORS THE ADVANTAGE OF OMNI-EC™ ECM TECHNOLOGY PROTECTED INVESTMENT Industry-leading 3-Year Full Replacement Warranty (nonprorated) on Omni-EC™ Motor & Drive Combination. 3 YEAR WARRANTY Suitable for 50 Hz and 60 Hz applications. REDUCE DOWNTIME & MAINTENANCE COSTS Eliminate belts, pulleys, and bearings for less downtime and lower maintenance costs. PRECISION VENTILATION CONTROL Unlike traditional induction motors that slow down under load, our EC motor automatically adjusts torque to maintain a consistent speed across a wide range of settings, giving you superior control over your ventilation system. BUILT-IN PROTECTION Features overload protection safeguarding against overheating for lasting performance. Unlike outdated induction direct drive fans that fail in hot weather, the Omni-EC™ motor will continually monitor speed and motor thermal conditions to ensure reliable airflow when you need it most! NO REMOTE DRIVE The drive is embedded directly in the motor, simplifying installation and reducing potential failure points. ENERGY EFFICIENT PERFORMANCE Advanced, energy-efficient Electronically Commutated motors adjust their speed automatically to match airflow needs. This ensures consistent performance while reducing energy consumption and operating costs. LONG LASTING RELIABILITY Built with premium components for years of dependable performance. ACTIVE POWER FACTOR CORRECTION (PFC) Reduces noise and current fluctuations typical of standard VFD/ECM systems, delivering amperage draw comparable to traditional beltdriven motors while enabling smaller electrical circuit requirements.
ENERGY REBATES MAY BE AVAILABLE. For more information, contact: Ross Thompson, Hog Slat Ventilation Director rdthompson@hogslat.com (309) 831-6881 $ ADVANCED MOTOR PROTECTION The EC motor features built-in limits for wattage, amperage, and temperature to prevent damage from overloads, ensuring lasting performance. • Power Limit: The motor adjusts RPM twice per second to stay below 2000W, increasing speed as load allows. • Thermal control: Reduces motor speed when the temperature exceeds the threshold, polling every 5 seconds until optimal levels are restored. • Automatic Restart: Enables the motor to automatically resume operation once power is stabilized, ensuring continuous ventilation without the need for manual reset after voltage fluctuations. AIRSTORM PRO™ KEY PERFORMANCE SPECS • Powerful Airflow: 2.28 HP motor delivers robust performance for optimal ventilation. • Optimized Speed: Adjustable speed range (400-700 RPM) allows you to fine-tune airflow to your specific needs. • Energy Efficient: Operates on standard 208-253V power with a low current draw (8.5 Amps). • Smooth Operation: Soft start and stop features extend motor life and reduce stress on components. • Reliable Shutter Opening: “Break Away” feature ensures shutters open fully every time, guaranteeing consistent airflow.
THE AIRSTORM PRO™ ADVANTAGE FEATURE BENEFIT Integrated Motor & Drive (No External Units) Electronically Commutated Motor (ECM) Soft Start & Overload Protection Self-Adjusting Wattage & Thermal Control Fixed & Variable Speed Options Easy Retrofit Unmatched Warranty (Motor & Drive) Simplified Installation: No external VFDs or complex wiring is needed; saving time and money. Optimal Airflow: Precisely controls torque and speed to deliver optimal airflow tailored to your ventilation needs. Extended Motor Life: Prevents burnout from heat and pressure, maximizing motor lifespan. Continuous Operation: Automatically reduces output to prevent overheating, eliminating costly downtime. Configurable Performance: Supports both fixed-speed and variable (0–10V or 10–0V) inputs to achieve precise CFM and energy efficiency (CFM/watt) targets. Seamless Upgrade: Retrofit Kits are available to upgrade existing AirStorm 54” ventilation fans. Protected Investment: Industry-leading 3-Year Full Replacement Warranty (non-prorated) on Omni-EC™ Motor & Drive Combination. TM The AirStorm Pro™ fan line is designed with corrosion-resistant materials, featuring a through-wall mount, gel-coated fiberglass housing, stainless steel prop, optional poly discharge cone, and plastic vane shutter. The X-Brace delivers superior fan rigidity by anchoring to housing corners, while rubber mounts dampen vibration for extended fan life. With stainless steel hardware, this corrosion-resistant support ensures lasting performance. Stainless steel prop designed for peak air delivery at typical operating static pressures, providing high airflow at higher speeds and energy efficiency at lower speeds. Durable PVC frame and airfoil vanes ensure smooth airflow and longlasting performance. RIGID X-BRACE SUPPORT STAINLESS STEEL PROP LOW-MAINTENANCE SHUTTERS SMART FEATURES. REAL BENEFITS.
PERFORMANCE (in.H2O) (cfm) RPM Volts Amps Watts cfm/Watt Static Pressure Airflow 0.00 33900 655 230.4 8.31 1904 17.8 0.05 32500 651 230.0 8.53 1952 16.7 0.10 30900 651 230.0 8.79 2011 15.4 0.15 29500 651 229.9 9.09 2078 14.2 0.20 26400 623 230.4 8.26 1894 14.0 0.25 24300 621 230.0 8.42 1923 12.6 0.30 21200 623 230.1 8.46 1938 11.0 Setting #9 (in.H2O) (cfm) RPM Volts Amps Watts cfm/Watt Static Pressure Airflow 0.00 27500 533 230.7 4.64 1072 25.7 0.05 26300 531 230.7 4.80 1108 23.7 0.10 24500 531 230.3 5.04 1161 21.1 0.15 22100 531 230.1 5.26 1210 18.3 0.20 18600 532 229.8 5.32 1221 15.3 0.25 13400 533 229.8 5.32 1230 10.9 0.30 10300 530 230.2 5.74 1320 7.8 Setting #4 (in.H2O) (cfm) RPM Volts Amps Watts cfm/Watt Static Pressure Airflow 0.00 33800 653 230.9 8.24 1895 17.8 0.05 32500 650 230.8 8.50 1951 16.7 0.10 30900 651 230.1 8.77 2008 15.4 0.15 29500 651 230.1 9.06 2073 14.2 0.20 27900 651 230.2 9.30 2127 13.1 0.25 24100 617 230.4 8.20 1878 12.9 0.30 20700 621 230.4 8.35 1911 10.8 Setting #8 (in.H2O) (cfm) RPM Volts Amps Watts cfm/Watt Static Pressure Airflow 0.00 26400 503 229.8 3.92 897 29.4 0.05 24600 501 229.8 4.12 949 25.9 0.10 22300 501 229.4 4.36 1002 22.3 0.15 19200 502 229.2 4.50 1029 18.7 0.20 14700 503 229.1 4.48 1019 14.4 0.25 10700 502 231.1 4.70 1090 9.8 0.30 7500 502 231.5 5.10 1179 6.4 Setting #3 (in.H2O) (cfm) RPM Volts Amps Watts cfm/Watt Static Pressure Airflow 0.00 33500 637 231.6 7.54 1741 19.2 0.05 32000 633 231.6 7.70 1780 18.0 0.10 29500 633 231.1 8.12 1881 15.7 0.15 28100 634 231.1 8.36 1935 14.5 0.20 27100 634 231.1 8.56 1971 13.8 0.25 25200 633 230.5 8.78 2023 12.5 0.30 22900 634 230.7 8.90 2059 11.1 Setting #7 (in.H2O) (cfm) RPM Volts Amps Watts cfm/Watt Static Pressure Airflow 0.00 24700 468 230.5 3.16 723 34.1 0.05 22200 465 230.4 3.38 774 28.7 0.10 19600 465 230.2 3.54 809 24.2 0.15 15800 466 230.2 3.64 830 19.1 0.20 10900 467 230.2 3.74 861 12.6 0.25 7800 468 229.8 4.12 949 8.2 Setting #2 (in.H2O) (cfm) RPM Volts Amps Watts cfm/Watt Static Pressure Airflow 0.00 31800 606 231.7 6.52 1513 21.0 0.05 29700 603 231.6 6.82 1583 18.7 0.10 28200 604 231.1 7.10 1636 17.2 0.15 27100 604 230.3 7.32 1688 16.1 0.20 25200 603 230.3 7.54 1740 14.5 0.25 22800 604 230.7 7.72 1777 12.8 0.30 18800 605 230.2 7.64 1760 10.7 Setting #6 (in.H2O) (cfm) RPM Volts Amps Watts cfm/Watt Static Pressure Airflow 0.00 22500 437 230.7 2.70 615 36.6 0.05 20400 435 230.5 2.82 650 31.4 0.10 17000 435 230.3 2.98 685 24.8 0.15 11700 437 230.1 3.04 702 16.7 0.20 8300 437 230.6 3.32 756 11.0 0.25 4000 437 230.7 3.52 808 5.0 Setting #1 (in.H2O) (cfm) RPM Volts Amps Watts cfm/Watt Static Pressure Airflow 0.00 29400 569 230.4 5.54 1277 23.1 0.05 27800 568 230.7 5.80 1337 20.8 0.10 26700 568 230.6 6.00 1372 19.5 0.15 24900 568 230.7 6.20 1426 17.5 0.20 22300 568 230.7 6.40 1477 15.1 0.25 18200 569 230.3 6.38 1464 12.4 0.30 13500 567 230.0 6.50 1496 9.0 Setting #5 (in.H2O) (cfm) RPM Volts Amps Watts cfm/Watt Static Pressure Airflow 0.00 20500 402 230.8 2.16 490 41.9 0.05 17400 399 230.8 2.29 523 33.4 0.10 13200 400 230.8 2.37 543 24.2 0.15 8600 401 230.7 2.53 578 14.8 0.20 3800 399 230.8 2.74 626 6.0 Setting #0 *Data taken from BESS Labs Test 24064 TM
SMART VENTILATION Our EC motors work seamlessly with thermostats and sensors using a 0-10V or 10-0V signal, automatically adjusting fan speed to maintain optimal conditions. • Fail-Safe Mode: With 10-0V control, EC motors default to maximum speed if the control signal is lost, ensuring critical ventilation even in system failure. SPEED & DIRECTION CONTROL The rotary switch (0–9) sets RPM or caps variable speed. DIP switches control the voltage input type, speed control mode, and rotation direction. 0 1 2 3 4 5 6 7 8 9 400 RPM 433 RPM 466 RPM 500 RPM 533 RPM 567 RPM 700 RPM 667 RPM 633 RPM 600 RPM For fixed speed operation DIP switch positions should be as follows: Fixed Speed Set Up (On/Off) For variable speed operation DIP switch positions should be as follows: Variable Speed Set Up (0-10/10-0 Voltage Control) DIR_SPEED: Ω, SPEED_SET: Ω, VOLT_SET: Ω 0-10V: DIR_SPEED Ω,SPEED_SET ≈, VOLT_SET Ω START/STOP CONTROL • Uses line voltage cycling through a controller relay • Supports traditional 0-10V or 10-0V control • Note: Requires a minimum off time of 60 seconds Option 1: Line Voltage Cycling Control • Maintains constant power with voltage signal control • Treats 0-0.9V as off (10-10.1 in a 10-0V scale), allowing continuous power • No minimum off time required Option 2: Constant Power Voltage Control 0 20 40 60 80 100 0 1 2 3 4 5 6 7 8 9 10 RPM Signal Voltage RPM curves based on voltage signal 0-10V 10-0V 0 20 40 60 80 100 0 1 2 3 4 5 6 RPM Signal Voltage RPM curves based on voltage signa 0-10V 10-0V RPM curves based on voltage signal RPM % 10-0V: DIR_SPEED Ω,SPEED_SET ≈, VOLT_SET ≈
PRECISE CONTROL OVER FAN SPEED AND AIRFLOW Variable voltage signal to control speed and performance. TM Signal Voltage Setting 9 Setting 8 Setting 7 Setting 6 Setting 5 Setting 4 Setting 3 Setting 2 Setting 1 Setting 0 -0.05” H20 0-10 10-0 rpm cfm rpm cfm rpm cfm rpm cfm rpm cfm rpm cfm rpm cfm rpm cfm rpm cfm rpm cfm 0-0.9 9.1-10 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1 9 400 13500 400 13500 400 13500 400 13500 400 13500 400 13500 400 13500 400 13500 400 13500 400 13500 2 8 440 17300 430 16400 430 16400 430 16400 420 15400 420 15400 410 14500 410 14500 400 13500 400 13500 3 7 480 20700 470 19800 460 19000 450 18000 440 17300 430 16400 430 16400 420 15400 410 14500 400 13500 4 6 510 22900 500 22300 490 21400 480 20700 460 19000 450 18000 440 17300 430 16400 410 14500 400 13500 5 5 550 25600 530 24500 520 23700 500 22300 480 20700 470 19800 450 18000 430 16400 420 15400 400 13500 6 4 590 27900 570 26800 550 25600 530 24500 500 22300 480 20700 460 19000 440 17300 420 15400 400 13500 7 3 630 29500 600 28400 570 26800 550 25600 530 24500 500 22300 480 20700 450 18000 420 15400 400 13500 8 2 650 30900 630 29500 600 28400 580 27400 550 25600 520 23700 490 21400 460 19000 430 16400 400 13500 9-10 1-0 650 30900 650 30900 630 29500 600 28400 570 26800 530 24500 500 22300 470 19800 430 16400 400 13500 Signal Voltage Setting 9 Setting 8 Setting 7 Setting 6 Setting 5 Setting 4 Setting 3 Setting 2 Setting 1 Setting 0 -0.10” H20 0-10 10-0 rpm cfm rpm cfm rpm cfm rpm cfm rpm cfm rpm cfm rpm cfm rpm cfm rpm cfm rpm cfm 0-0.9 9.1-10 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1 9 400 8600 400 8600 400 8600 400 8600 400 8600 400 8600 400 8600 400 8600 400 8600 400 8600 2 8 440 12900 430 11700 430 11700 430 11700 420 10500 420 10500 410 9300 410 9300 400 8600 400 8600 3 7 480 17200 470 16200 460 15100 450 1400 440 12900 430 11700 430 11700 420 10500 410 9300 400 8600 4 6 510 20000 500 19200 490 18100 480 17200 460 15100 450 1400 440 12900 430 11700 410 9300 400 8600 5 5 550 23400 530 22100 520 21000 500 19200 480 17200 470 16200 450 1400 430 11700 420 10500 400 8600 6 4 590 26200 570 24900 550 23400 530 22100 500 19200 480 17200 460 15100 440 12900 420 10500 400 8600 7 3 630 28100 600 27100 570 24900 550 23400 530 22100 500 19200 480 17200 450 1400 420 10500 400 8600 8 2 650 29500 630 28100 600 27100 580 25500 550 23400 520 21000 490 18100 460 15100 430 11700 400 8600 9-10 1-0 650 29500 650 29500 630 28100 600 27100 570 24900 530 22100 500 19200 470 16200 430 11700 400 8600 Signal Voltage Setting 9 Setting 8 Setting 7 Setting 6 Setting 5 Setting 4 Setting 3 Setting 2 Setting 1 Setting 0 -0.15” H20 0-10 10-0 rpm cfm rpm cfm rpm cfm rpm cfm rpm cfm rpm cfm rpm cfm rpm cfm rpm cfm rpm cfm 0-0.9 9.1-10 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1 9 400 3800 400 3800 400 3800 400 3800 400 3800 400 3800 400 3800 400 3800 400 3800 400 3800 2 8 440 8500 430 7300 430 7300 430 7300 420 6100 420 6100 410 4850 410 4850 400 3800 400 3800 3 7 480 13000 470 11900 460 10800 450 9600 440 8500 430 7300 430 7300 420 6100 410 4850 400 3800 4 6 510 16100 500 15100 490 14000 480 13000 460 10800 450 9600 440 8300 430 7300 410 4850 400 3800 5 5 550 20000 530 18100 520 17100 500 15100 480 13000 470 11900 450 9600 430 7300 420 6100 400 3800 6 4 590 23600 570 21900 550 20000 530 18100 500 15100 480 13000 460 10800 440 8300 420 6100 400 3800 7 3 630 26900 600 25200 570 21900 550 20000 530 18100 500 15100 480 13000 450 9600 420 6100 400 3800 8 2 650 27900 630 26900 600 25200 580 22800 550 20000 520 17100 490 14000 460 10800 430 7300 400 3800 9-10 1-0 650 27900 650 27900 630 27100 600 25200 570 22300 530 18600 500 14700 470 11900 430 7300 400 3800 Signal Voltage Setting 9 Setting 8 Setting 7 Setting 6 Setting 5 Setting 4 Setting 3 Setting 2 Setting 1 Setting 0 -0.20” H20 0-10 10-0 rpm cfm rpm cfm rpm cfm rpm cfm rpm cfm rpm cfm rpm cfm rpm cfm rpm cfm rpm cfm 0-0.9 9.1-10 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1 9 400 17400 400 17400 400 17400 400 17400 400 17400 400 17400 400 17400 400 17400 400 17400 400 17400 2 8 440 20700 430 20000 430 20000 430 20000 420 19400 420 19400 410 18400 410 18400 400 17400 400 17400 3 7 480 23200 470 22500 460 21900 450 21300 440 20700 430 20000 430 20000 420 19400 410 18400 400 17400 4 6 510 25100 500 24600 490 23900 480 23200 460 21900 450 21300 440 20700 430 20000 410 18400 400 17400 5 5 550 27100 530 26250 520 25700 500 24600 480 23200 470 22500 450 21300 430 20000 420 19400 400 17400 6 4 590 29000 570 28500 550 27100 530 26250 500 24600 480 23200 460 21900 440 20700 420 19400 400 17400 7 3 630 32000 600 29700 570 28500 550 27100 530 26250 500 24600 480 23200 450 21300 420 19400 400 17400 8 2 650 32500 630 32000 600 29700 580 26900 550 27100 520 25700 490 23900 460 21900 430 20000 400 17400 9-10 1-0 650 32500 650 32500 630 32000 600 29700 570 28500 530 26250 500 24600 470 22500 430 20000 400 17400 VOLTAGE PERFORMACE
